Product Description
Material: Stainless steel
Lampholder: GY16/Tungsten halogen lamp
Annex: with joysticker
Main Specification
| Type | Voltage | Power | Lamp holder | Illuminant | Luminous flux (lm) |
Material | Protection Class |
Cable Outside Diameter |
Weight |
| TG26 | 24V | 250W | G6.35 | Tungsten Halogen Lamp |
5600 | Stainless Steel | IP56 | ∅10-∅12 | 20.5kg |
| 220V/50HZ/ 220V/60HZ |
300W | GY9.5 | 6900 | ||||||
| 500W | 12500 | ||||||||
| TG27 | 220V/50HZ/ 220V/60HZ |
1000W | GY9.5 | Tungsten Halogen Lamp |
23000 | Stainless Steel | IP56 | ∅10-∅12 | 20.5kg |
| TG28 | 220V/50HZ/ 220V/60HZ |
2000W | GY16 | Tungsten Halogen Lamp |
53000 | Stainless Steel | IP56 | ∅12-∅14 | 30kg |
| TG26-A | 220V/50HZ/ 220V/60HZ |
300W | GY9.5 | Tungsten Halogen Lamp |
6900 | Stainless Steel | IP56 | ∅13-∅18 | 24.5kg |
| 500W | 12500 | ||||||||
| TG27-A | 220V/50HZ/ 220V/60HZ |
1000W | GY9.5 | Tungsten Halogen Lamp |
23000 | Stainless Steel | IP56 | ∅13-∅18 | 24.5kg |
| TG28-A | 220V/50HZ/ 220V/60HZ |
2000W | GY16 | Tungsten Halogen Lamp |
53000 | Stainless Steel | IP56 | ∅14-∅16 | 60.5kg |
| TG26-B | 220V/50HZ/ 220V/60HZ |
300W | G6.35 | Tungsten Halogen Lamp |
6900 | Stainless Steel | IP56 | ∅10-∅12 | 16.5kg |
| 500W | GY9.5 | 12500 | |||||||
| TG27-B | 220V/50HZ/ 220V/60HZ |
1000W | GY9.5 | Tungsten Halogen Lamp |
23000 | Stainless Steel | IP56 | ∅10-∅12 | 16.5kg |
| TG28-B | 220V/50HZ/ 220V/60HZ |
2000W | GY16 | Tungsten Halogen Lamp |
53000 | Stainless Steel | IP56 | ∅10-∅14 | 30kg |
