1. This navigation signal light’s shell is made of high-strength engineering plastic PA+GF, the lampshade adopts injection of PC, lens hood adopts good quality stainless steel.
2. The navigation signal lights have the whole seal structure, it is waterproof under the bad environment.
3. It can work under the temperature -30℃ to 55℃.
| IMPA Code | 370422 | 370423 | 370421 | 370424 | 370426/27/28 |
| Item Name | CXH1-21P | CXH2-21P | CXH3-21P | CXH4-21P | CXH6-21P |
| Item Type | Starboard Light | Port Light | Masthead Light | Stern Light | All-round Light |
| Visibility | 2n.m | 2n.m | 5n.m | 2n.m | 2n.m |
| Level Arc | 112.5° | 112.5° | 225° | 135° | 360° |
| Color | Green | Red | White | White/ Yellow | Green/ Red/ White |
| Power | 25W | 25W | 25W | 25W | 25W |
| Weight | 1.2 KGS | 1.2 KGS | 1.2 KGS | 1.2 KGS | 1.0 KGS |
